Description
Product Specifications
- Nominal Voltage (V) -25.6
- Nominal Capacity (Wh)- 2840
- Usable Capacity (Wh)- 2550
- Dimension (mm) -442*420*120
- Weight (Kg) -26.5
- Discharge Voltage (V)- 23.2 ~ 28.5
- Charge Voltage (V) -28.2 ~ 28.5
- Recommend Charge/Discharge Current (A) -55
- Max. Charge/Discharge Current (A) -85
- Peak Charge/Discharge Current (A) – 100A@15sec
- Communication – RS485 / CAN
- Configuration (max. in 1 battery group)- 20pcs
Features:
➢ The whole module is non-toxic, non-polluting and environmentally friendly;
➢ Cathode material is made from LiFePO4 with safety performance and long cycle life;
➢ Battery management system (BMS)has protection functions including over-discharge, overcharge, over-current and high/low temperature;
➢ The system can automatically manage charge and discharge state and balance current
and voltage of each cell;
➢ Flexible configuration, multiple battery modules can be in parallel for expanding capacity
and power
➢ Adopted self-cooling mode rapidly reduced system entire noise;
The module has less self-discharge, up to 6 months without charging it on shelf, no memory
effect, excellent performance of shallow charge and discharge;
➢ Working temperature range is from -10℃ to 55℃, (Charging 0~55℃; discharging -10~55℃)
with excellent discharge performance and cycle life;
➢ Small size and light weight, standard of 19-inch embedded designed module is comfortable
for installation and maintenance
Download the UP2500 Product Manualmanual-bateria-de-litio-pylontech-up2500
